K8S上使用helm部署 Prometheus + Grafana

news2025/6/6 16:38:47

一、使用 Helm 安装 Prometheus

1. 配置源

地址：prometheus 27.19.0 · prometheus/prometheus-community

# 添加repo
$ helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
"prometheus-community" has been added to your repositories

$ helm repo update prometheus-community
Hang tight while we grab the latest from your chart repositories...
...Successfully got an update from the "prometheus-community" chart repository
Update Complete. ⎈Happy Helming!⎈

$ helm search repo prometheus-community
NAME                                                    CHART VERSION   APP VERSION     DESCRIPTION
prometheus-community/alertmanager                       1.19.0          v0.28.1         The Alertmanager handles alerts sent by client ...
prometheus-community/alertmanager-snmp-notifier         1.0.0           v2.0.0          The SNMP Notifier handles alerts coming from Pr...
prometheus-community/jiralert                           1.7.2           v1.3.0          A Helm chart for Kubernetes to install jiralert
prometheus-community/kube-prometheus-stack              72.7.0          v0.82.2         kube-prometheus-stack collects Kubernetes manif...
prometheus-community/kube-state-metrics                 5.33.2          2.15.0          Install kube-state-metrics to generate and expo...
prometheus-community/prom-label-proxy                   0.12.2          v0.11.0         A proxy that enforces a given label in a given ...
prometheus-community/prometheus                         27.16.0         v3.4.0          Prometheus is a monitoring system and time seri...
prometheus-community/prometheus-adapter                 4.14.1          v0.12.0         A Helm chart for k8s prometheus adapter
prometheus-community/prometheus-blackbox-exporter       9.7.0           v0.26.0         Prometheus Blackbox Exporter
prometheus-community/prometheus-cloudwatch-expo...      0.27.0          0.16.0          A Helm chart for prometheus cloudwatch-exporter
prometheus-community/prometheus-conntrack-stats...      0.5.19          v0.4.27         A Helm chart for conntrack-stats-exporter

2. 下载 prometheus 包

# 拉包
$ helm pull prometheus-community/prometheus

$ ll
total 88
drwxr-xr-x 2 root   root    4096 Jul 16 03:12 ./
drwxrwxr-x 9 ubuntu ubuntu  4096 Jul 16 03:10 ../
-rw-r--r-- 1 root   root   80137 Jul 16 03:12 prometheus-27.16.0.tgz

# 解包
$ tar -zxvf prometheus-27.16.0.tgz

###修改存储，需修改2处
vim values.yaml

## Prometheus server data Persistent Volume Storage Class
    ## If defined, storageClassName: <storageClass>
    ## If set to "-", storageClassName: "", which disables dynamic provisioning
    ## If undefined (the default) or set to null, no storageClassName spec is
    ##   set, choosing the default provisioner.  (gp2 on AWS, standard on
    ##   GKE, AWS & OpenStack)
    ##
    storageClass: "managed-nfs-storage"  ###修改为自己的动态存储名称

    ## Subdirectory of Prometheus server data Persistent Volume to mount
    ## Useful if the volume's root directory is not empty
    ##
    subPath: ""


vim charts/alertmanager/values.yaml

persistence:
  enabled: true
  ## Persistent Volume Storage Class
  ## If defined, storageClassName: <storageClass>
  ## If set to "-", storageClassName: "", which disables dynamic provisioning
  ## If undefined (the default) or set to null, no storageClassName spec is
  ## set, choosing the default provisioner.
  ##
  storageClass: "managed-nfs-storage" ###修改为自己的动态存储名称
  accessModes:
    - ReadWriteOnce
  size: 50Mi



#####部署

 helm install prometheus ./ -n prometheus

二、使用 Helm 安装 Grafana

1. 配置源

地址：grafana 9.2.2 · grafana/grafana

$ helm repo add grafana https://grafana.github.io/helm-charts
"grafana" has been added to your repositories

$ helm repo update grafana
Hang tight while we grab the latest from your chart repositories...
...Successfully got an update from the "grafana" chart repository
Update Complete. ⎈Happy Helming!⎈

$ helm search repo grafana/grafana
NAME                            CHART VERSION   APP VERSION     DESCRIPTION
grafana/grafana                 9.2.2           12.0.1          The leading tool for querying and visualizing t...
grafana/grafana-agent           0.42.0          v0.42.0         Grafana Agent
grafana/grafana-agent-operator  0.5.1           0.44.2          A Helm chart for Grafana Agent Operator
grafana/grafana-operator        v5.18.0         v5.18.0         Helm chart for the Grafana Operator
grafana/grafana-sampling        1.1.5           v1.7.5          A Helm chart for a layered OTLP tail sampling a...

2. 安装 grafana

$  helm install grafana grafana/grafana -n grafana --create-namespace
NAME: grafana
LAST DEPLOYED: Tue Jun  3 13:51:47 2025
NAMESPACE: grafana
STATUS: deployed
REVISION: 1
NOTES:
1. Get your 'admin' user password by running:

   kubectl get secret --namespace grafana grafana -o jsonpath="{.data.admin-password}" | base64 --decode ; echo


2. The Grafana server can be accessed via port 80 on the following DNS name from within your cluster:

   grafana.grafana.svc.cluster.local

   Get the Grafana URL to visit by running these commands in the same shell:
     export POD_NAME=$(kubectl get pods --namespace grafana -l "app.kubernetes.io/name=grafana,app.kubernetes.io/instance=grafana" -o jsonpath="{.items[0].metadata.name}")
     kubectl --namespace grafana port-forward $POD_NAME 3000

3. Login with the password from step 1 and the username: admin
#################################################################################
######   WARNING: Persistence is disabled!!! You will lose your data when   #####
######            the Grafana pod is terminated.                            #####
#################################################################################

3. 访问

web 访问：https://yourip：port

账号：admin，密码通过下面命令获取

$ kubectl get secret --namespace grafana grafana -o jsonpath="{.data.admin-password}" | base64 --decode ; echo
0D0NfEWWFx9qsBiKR8PuFVxf6PPa9o8YGhZZaNXY
